PRODUCT NAME：
ZEGA D545 Integrated DTH Surface Drill Rig
Main Specifications
Diesel Engine
Cummins
Rated Power
194kW
DTH Hammer
4"
Hole Range
φ108-127mm(φ108-138mm)
Drill Pipe
φ76mm
F.A.D.
15m3/min(16m3/min)
Air Discharge Pressure
17 Bar
Torque
2,479N.m
Max.Pullup Force
40kN
Tamming Speed
High Speed :3km/hlow speed: 2km/h
Slope Capability
25º
Track Frame Oscillation
±14º
Weight
11,300Kg
