PRODUCT NAME：
T635 Automatic Integrated Top Hammer Drill Rig
T635 Main Specification
Drifter Model
ZY-103
Hole Range
64-102mm
Drill Pipe
T38(T45)*3660mm
Max.Impact Power
15kW
Diesel Engine
Cummins 119kw
Feed/Pullup Force
20kN/20kN
Road Handling system/ Road Storage
4+1(Auto)
F.A.D.
5.4m3/min
Max.Pressure
8.5bar
Slope Capability
25º
Track Frame Oscillation
±10º
Tramming Speed
High Speed:3.8km/hLow Speed:1.9km/h
Weight
11,000Kg
